Universal Milling Machine X6132
$10000
| Specification | X6132 | X6132B | X6132H | X6132BH |
| Table size | 320×1325 | 320×1600 | 320×1325 | 320×1600 |
Max longitudinal travel (manual/automatic) |
700/680 |
900/880 |
700/680 |
900/880 |
Max cross travel(manual/automatic) |
255/240 |
|||
Max vertical travel(manual/automatic) |
320/300 |
410/390 |
||
Max rotary angle of table |
±45° |
|||
Distance between spindle and table surface |
30/350 |
30/440 | ||
Spindle speed step |
18 steps |
|||
Spindle speed range |
30~1500 |
|||
Feed range of table travel |
18 steps |
|||
| Table feed range | 23.5-1180/23.5-1180/8-394 | |||
| Main motor power | 7.5 | |||
| Feed motor power | 1.5 | |||
| Overall size | 2294×1770×1610 | 2294×2050×1610 | 2294×1770×1790 | 2294×2050×1790 |
Net weight/Gross weight |
2650/2950 |
2740/3040 |
2850/3150 |
2940/3240 |
