Gantry Machining Center GMC3022
$102000
|
Machine Model |
Unit |
GMC 3022 |
|
|
Control system |
|
Mitsusibishi M80A |
|
|
Worktable |
Table size |
mm |
3000*1800 |
|
|
Maximum load capacity |
T |
16 |
|
Travel |
X axis travel |
mm |
3200 |
|
|
Y axis travel |
mm |
2200 |
|
|
Z axis travel |
mm |
1000 |
|
Spindle |
Spindle speed |
r/min |
8000 |
|
|
Main motor |
Kw |
22 |
|
|
Spindle face to table surface |
mm |
200-1200 |
|
|
Taper |
|
BT50/190 |
|
X/Y/Z axis motor torque |
Nm |
36/36/36 |
|
|
Feed |
X axis rapid traverse speed |
m/min |
15 |
|
|
Y axis rapid traverse speed |
m/min |
15 |
|
|
Z axis rapid traverse speed |
m/min |
10 |
|
Max. cutting feed |
mm/min |
8000 |
|
|
Tool magazine capacity |
|
pcs |
24 |
|
Tool change time (T-T) |
|
s |
2 |
|
Positioning accuracy |
X axis |
mm |
±0.005/300 |
|
|
Y axis |
mm |
±0.005/300 |
|
|
Z axis |
mm |
±0.005/300 |
|
Repeat Positioning Accuracy |
X axis |
mm |
±0.008 |
|
|
Y axis |
mm |
±0.007 |
|
|
Z axis |
mm |
±0.005 |
|
Verticality (x/y axis) |
mm |
±0.015/300 |
|
|
Machine size |
mm |
8500×3800×3300 |
|
|
Net weight |
T |
26 |
|
