Gantry Machining Center GMC2016
$63800
|
Machine Model |
Unit |
GMC2016 |
|
|
Control system |
|
Mitsusibishi M80A or FANUC 0i MF（5） |
|
|
Worktable |
Table size |
mm |
2000*1400 |
|
|
Maximum load capacity |
T |
8 |
|
Travel |
X axis travel |
mm |
2200 |
|
|
Y axis travel |
mm |
1600 |
|
|
Z axis travel |
mm |
800 |
|
Spindle |
Spindle speed |
r/min |
8000 |
|
|
Main motor |
Kw |
15/18.5 |
|
|
Spindle face to table surface |
mm |
150-950 |
|
|
Taper |
|
BT50/155 |
|
X/Y/Z axis motor torque |
Nm |
35/35/35 |
|
|
Feed |
X axis rapid traverse speed |
m/min |
24 |
|
|
Y axis rapid traverse speed |
m/min |
24 |
|
|
Z axis rapid traverse speed |
m/min |
24 |
|
Max. cutting feed |
mm/min |
10000 |
|
|
Tool magazine capacity |
|
pcs |
24 |
|
Tool change time (T-T) |
|
s |
2 |
|
Positioning accuracy |
X axis |
mm |
0.02 |
|
|
Y axis |
mm |
0.016 |
|
|
Z axis |
mm |
0.015 |
|
Repeat Positioning Accuracy |
X axis |
mm |
0.014 |
|
|
Y axis |
mm |
0.012 |
|
|
Z axis |
mm |
0.010 |
|
Verticality (x/y axis) |
mm |
0.015/300 |
|
|
Machine size |
mm |
6700x3600x3650 |
|
|
Net weight |
T |
23 |
|
