Univeral Milling Machine Model X6132
$9500
This product has reliable structure,stable quality,easy operation and a perfect lubrication system.And also has high power spindle motor,wide variable range,give full play to the effectiveness of cutting tools,high-speed cutting and can withstand heavy cutting work.It is suitable for all types of machining,using a variety of rod-shaped cutter,circular cutter,angle cutter to milling plane,bevel,groove and gear.After configuring a round table or some other milling accessories can further expand use of machine tools.
| Model | X6132 | |
| TABLE | ||
| Table size | mm | 1320x320 |
| T slot | No. | 3 |
| Size (Width) | mm | 18 |
| Centre distance | mm | 70 |
| Max. load of Table | kg | 500 |
| Max.swivel of table | degree | ±45º |
| MACHINING RANGE | ||
| Table Longitudinal travel(manual/auto) | mm | 700/680 |
| Table Cross travel (manual/auto) | mm | 255/244 |
| Table Vertical travel(manual/auto) | mm | 320/300 |
| MAIN SPINDLE | ||
| Spindle taper | ISO50 | |
| Spindle speed /step | rpm | 30-1500/18steps |
| Table center to column surface | mm | 215-470 |
| Horizontal spindle axis to table surface | mm | 30-350 |
| Distance from spindle axis to ram | mm | 155 |
| FEEDS | ||
| Longitudinal/cross feed | mm / min | XY:23.5-1180 |
| Vertical/step | mm/min | 8-394/18steps |
| Longitudinal/cross rapid speed | mm / min | XY:2300 |
| Rapid Traverse vertical | mm/min | 770 |
| POWER | ||
| Main motor | kw | 7.5 |
| Feed motor | kw | 1.5 |
| Coolant motor | kw | 0.125 |
| OTHERS | ||
| Package dimension | cm | 226x178x199 |
| Overall dimension | cm | 2294*1770*1904 |
| N.W/G.W | kg | 2650/3000 |
